TGG1 / Myrosinase 1 antibody

WB analysis of Arabidopsis leaf extract using GTX00932 TGG1 / Myrosinase 1 antibody. Molecular mass of TGG1 is 61 kDa from the amino acid sequence. The protein undergoes modifications such as elimination of signal peptide and glycosylation at 9 positions, which chages molecular mass in mature form.
Dilution : 1:1000
Loading : 10 μg

ICC/IF analysis of Arabidopsis rosette leaves (48-day-old plants) using GTX00932 TGG1 / Myrosinase 1 antibody. Asterisks show myrosin cells.
CW: cell wall; V: vacuole
(a, c): stained with CBB
(b,d): Primary antibody
c and d are enlarged images of the boxed area of a and b, respectivey.
(e): Ultrathin sections were mounted on Formvar-coated nicke grid by immunoelectron microscopy.
Dilution : 1:1000
